Part #: NX-813-LEDRMW

Recessed Adjustable LED Edge-Lit Exit Sign, AC Only, 6-inch Red Letters, Single Face / Mirrored Acrylic, White Housing

Part #: NX-813-LEDRMW

Recessed Adjustable LED Edge-Lit Exit Sign, AC Only, 6-inch Red Letters, Single Face / Mirrored Acrylic, White Housing


$160.65 each

Sold in multiples of 1

Adding to cart… The item has been added

Description

Architectural acrylic edge-lit sign for applications requiring a recessed installation where the wiring compartment is concealed within a galvanized steel housing. Uses included, but are not limited to museums, galleries, office building lobbies, etc. Incorporates 25+ year LED source. 6" Red letters. AC only. Input Voltage: 120/277VAC Wattage: 3W Finish: White Face: Edge-lit single face; mirrored acrylic. Face is constructed with 0.40" clear acrylic with rounded and finished edge for attractive appearance. Face contains red 6” high and 3/4” thick lettering inside face to comply with NFPA requirements. Reflective stick-on chevrons provided and are applied to rear of panel in order for light to reflect off the inner face of the chevron tape to provide a similiar effect as the lettering embedded inside the acrylic. Face can be adjusted in the field from 0º to 90º for wall, ceiling or sloped applications. Body: Galvanized steel housing with die-cast cover plate and acrylic panel. Mounting: Two 13-3/4" to 24-1/2" adjustable bar hangers with captive nails are included on housing. Bar hangers are parallel to junction box, but can be repositioned 90° perpendicular to junction box if desired. A T-Bar notch allow for easy installation in a suspended ceiling. Testing: High charge / ready operation indicator light with test button and automatic reset. Listing: cULus Listed for Damp Locations, UL 924, Title 20, NFPA
Product Specification
Manufacturer Part Number
NX-813-LEDRMW
Item UPC
732180375219
Lighting Type
LED
Manufacturer
Nora Lighting
Manufacturer Description
NX-813-LEDRMW
Color Temperature Scale
Color Temperature Scale
Color Temperature (Kelvin)
N/A
Our Part#
NX-813-LEDRMW-NR
Dimension (Inches)
x x
DLC Certified
No
Watts
3W
Energy Star Certified
No
Weight (lbs)
0

Warranty Information

Standard Manufacturer's Limited Warranty
